inline-images

See the pictures in your Claude Code transcript.

inline-images is a mod for Claude Code. Many command-line tools print images with the iTerm2 inline images protocol: imgcat, it2cat, chafa -f iterm, timg -p iterm, wezterm imgcat, matplotlib backends and more. Claude Code does not show these images. You see "Ran 1 shell command", and the model reads a wall of base64.

This mod shows each image under the tool call that printed it. It also shows the images that Claude sends to you.

Without the mod	With the mod

The picture on the right is a real iTerm2 image, at full resolution, inside a running Claude Code session.

Contents

• Quick start
• Features
• Terminals
• Options
• How it works
• Troubleshooting
• FAQ
• Uninstall
• Develop

Quick start

1. Install the mod. Type this in a Claude Code session:

   /plugin install inline-images --marketplace chrisns/claude-image-cli-mod


   Answer y to add the marketplace. Then choose a scope.

2. Install Pillow, the image library that the mod uses:

   python3 -m pip install Pillow


3. For real pixels in iTerm2, do two more steps:

   • Run python3 -m pip install iterm2.
   • In iTerm2, open Settings > General > Magic and select Enable Python API.

4. Test it. Ask Claude:

   Download https://raw.githubusercontent.com/chrisns/claude-image-cli-mod/main/docs/fixtures/earth.jpg and show it with imgcat.

   If you do not have imgcat, this command prints the same sequence:

   printf '\033]1337;File=inline=1:%s\a\n' "$(base64 < earth.jpg | tr -d '\n')"


   You see the Earth under the Bash call, with a caption such as earth.jpg · 800×800 · JPEG · 141.6 KB.

Features

• Previews in the transcript. Each image appears under the tool call that printed it, with its name, size and format.
• Real pixels. iTerm2, kitty and Ghostty show the real image. Other terminals show a preview in coloured blocks.
• Images that Claude sends. An image file that Claude delivers with SendUserFile or SendUserMessage appears under the delivery.
• Click to open. Click a picture to open it in your system's viewer, for example Preview on macOS.
• A clean context. The model reads [inline image: earth.jpg, 141.6 KB, shown to the user], not 190,000 characters of base64.
• Large images. Claude Code cuts tool output at 30,000 characters. The mod reads the whole output from the file where Claude Code saves it.
• The right shape. The mod measures your terminal's cell size and keeps the picture's aspect ratio.
• The whole protocol. File=, chunked MultipartFile, the tmux passthrough wrapper, the BEL and ST terminators, width, height and preserveAspectRatio. A download (inline=0) is not shown, and its note says so.
• Transparency and several images in one command.

Terminals

Terminal	What you see	How
iTerm2	Real pixels	The iTerm2 overlay. It needs the iterm2 Python module and the Python API.
iTerm2 without the Python API	Coloured blocks	The cells renderer.
kitty, Ghostty	Real pixels	Claude Code's own Image element, which uses the kitty graphics protocol.
Any other terminal	Coloured blocks	The cells renderer. Each cell holds 2 by 2 blocks of colour.

This is the same photo in Ghostty:

This is the block preview that other terminals show:

Options

Change the options in the config menu of Claude Code, or under pluginConfigs in your settings.

Option	Default	What it does
renderer	auto	auto uses iterm in iTerm2, image in kitty and Ghostty, and cells in other terminals. You can also set iterm, image or cells.
max_columns	100	The widest that a preview can be, from 1 to 255 columns. A preview is never wider than the transcript.
max_rows	28	The tallest that a preview can be, from 1 to 255 rows.
palette	0	Reduce a block preview to this many colours, from 0 to 256. 0 keeps all colours. A value near 32 can look cleaner on a busy picture.
hide_from_model	true	Replace the image data in the tool result with a short note.
python	python3	The Python 3 that runs the helper and the iTerm2 overlay.

How it works

1. A ui.render hook looks for ESC ] 1337 ; File= in the output of each tool call.
2. mod/hooks/osc1337.ts reads the sequences.
3. mod/bin/render.py decodes the image and scales it to fit a box of cells. It reads the cell size from the terminal with TIOCGWINSZ.
4. The mod draws the box with the renderer that your terminal supports.
5. A transparent click layer (mod/hooks/click.tsx) lies over each picture. A click opens the picture.
6. A session.append hook removes the image data from what the model reads. The transcript keeps the whole output, so the preview comes back when you resume a session.

Real pixels in iTerm2

Claude Code owns the screen, so a mod cannot print an escape sequence. Claude Code's Image element uses kitty Unicode placeholders, and iTerm2 does not draw those. So the iterm renderer works beside Claude Code:

1. The mod draws the block preview. The first 5 cells of each row hold a hidden marker: braille glyphs in the colour of the cell. The marker carries the box's id and the row number.
2. mod/bin/iterm_overlay.py starts with the session. It watches the screen through the iTerm2 Python API.
3. When it finds a box, it writes the real image over it with the iTerm2 protocol. It saves the cursor before and restores it after.

How the overlay keeps the screen correct

Claude Code repaints only the cells that it thinks have changed. An image that is in the wrong place stays there. These rules prevent that:

• Each marker glyph includes the row number. When a box moves, every marker cell changes. Claude Code repaints them, and the overlay finds the box in its new place.
• A box must stay in one place for one look. The overlay reads the screen again just before it draws.
• The overlay draws only rows that show the box and nothing else. So an image never hides a hint or a menu that Claude Code draws over the transcript.
• If Claude Code repaints part of an image in place, the overlay draws the image again.
• A box that the edge of the screen cuts gets a cropped image.
• A large image goes as a chunked MultipartFile in one write. iTerm2 prints a single File= sequence of about 1 MB as text.

Troubleshooting

No preview, and the raw output shows. The mod is not loaded. Run /plugin and check that inline-images is enabled.

A dim line says no preview: …. The helper could not draw the image. The text after no preview: gives the reason:

• no image decoder: install Pillow, or set the python option to a Python that has it.
• not a supported image format: the mod draws only PNG, JPEG, GIF, WebP, BMP, TIFF and ICO.
• the image is too large: the image has more than 40 million pixels, which is too many to decode safely.

iTerm2 shows blocks, not real pixels.

1. Check that python3 -c "import iterm2" works in the Python that the python option names.
2. Check that iTerm2 > Settings > General > Magic > Enable Python API is on.
3. Start a new Claude Code session.

To see why the overlay is off, set the renderer option to iterm. A message then tells you the reason.

The picture tears while you scroll. In iTerm2, the overlay draws again when the screen stops moving. A picture can look broken for a moment during a fast scroll.

Over ssh. Real pixels need the mod and the terminal on the same machine. Over ssh you see the block preview.

FAQ

Can Claude see the images? No. The model reads a short note. To let Claude look at a picture, ask it to read the image file.

Why not sixel? Claude Code draws its screen itself. A mod can give it only text, cells and kitty images. The iTerm2 overlay is the one way to draw pixels beside it.

Where does the mod keep the images? In your user cache folder: ~/Library/Caches/inline-images on macOS, or ~/.cache/inline-images on Linux. Only your user can read the folder. The mod deletes files that are older than 24 hours.

Does it send anything over the network? No.

Is it safe to show an image from an unknown source? The mod treats all tool output as untrusted. Read SECURITY.md for what it does.

Why braille glyphs in the iTerm2 marker? No prompt, reply or diff uses them, and each glyph is one cell wide.

Uninstall

/plugin uninstall inline-images

To remove the marketplace too, run /plugin marketplace remove claude-image-cli-mod. To remove the cache, delete ~/Library/Caches/inline-images on macOS, or ~/.cache/inline-images on Linux.

Develop

Run the mod from a clone:

claude --plugin-dir ./mod

Run the checks:

claude plugin validate .
claude plugin test mod
python3 -m unittest discover -s mod/tests -p 'test_*.py'

The CI workflow runs the same checks on Linux and macOS, with Pillow and with ImageMagick.

To type-check, start one session with the mod, so that Claude Code writes the types into mod/.claude-plugin/types. Then run npx -p typescript tsc -p mod.

To see each draw of the iTerm2 overlay, start claude with INLINE_IMAGES_DEBUG=/tmp/overlay.log.

Screenshots

The scripts in scripts/ drive iTerm2 and Ghostty on macOS. They start a session with Haiku, send a prompt and save the window. Your terminal needs the Screen Recording permission.

scripts/screenshot.sh docs/screenshots/raw-with.png with 'Use the Bash tool to run ~/.iterm2/imgcat docs/fixtures/earth.jpg. Do not read the file yourself. Reply with the single word: done.'
python3 scripts/crop-screenshot.py docs/screenshots/raw-with.png docs/screenshots/with-mod.png

crop-screenshot.py removes the input box and the status lines.

Credits

• docs/fixtures/earth.jpg is The Earth seen from Apollo 17, a NASA photo in the public domain.
• docs/fixtures/earth-cutout.png is the same photo with a transparent background.
• docs/fixtures/gradient.png was made for this project. It is under the MIT licence.

Licence

MIT. See LICENSE.
