Gridpaper

The grid paper store doesn't stock the one you actually need. Make it yourself, in the exact spacing, color, and pattern you want, and print it in under a minute.

Created by Bilal Malik
Follow on Github bilalmlkdev

The Problem This Solves

Grid paper is one of those things that's almost never exactly right. The notebook at the store has 5mm squares when you needed 4mm. The dot grid is too faint to see or too dark to write over. You need one sheet of isometric paper for a single sketch and the only option is buying an entire pad of it.

So people end up hand-ruling paper, screenshotting grids off the internet at the wrong resolution, or just working on the wrong grid because the right one isn't available. None of that is a good use of anyone's time.

Gridpaper skips the compromise. Pick a pattern, set the exact spacing in mm or inches, pick a color and opacity, and print it - it's your grid, sized the way you actually need it, not the way a notebook manufacturer decided to sell it.

What You Actually Get

• You're not limited to whatever a store happens to stock. Ten-plus patterns ship built in - dot grid, lined, square, isometric, hex, cross, graph, large dot, music staff, isometric dots - covering journaling, sketching, drafting, tabletop maps, and composition without hunting down a specialty notebook for each one.
• You stop eyeballing spacing. A slider or a direct numeric input sets the exact gap between lines, in millimeters or inches, with the ruler updating live so what you see is what prints.
• You get the contrast you actually want. Pick any color, dial opacity from barely-there to bold, and reset to default in one click if you overshoot.
• What prints is just the grid. No ads, no UI chrome, no browser print artifacts - a clean sheet, accurately rendered, ready for a printer tray.
• Your setup is still there next time. Pattern, spacing, color, and opacity are saved locally the moment you set them - no account, no sign-in, nothing to lose if you close the tab.

How It Works Under the Hood

Every pattern is its own renderer - drawDotGrid, drawHexGrid, drawMusicStaff, and so on - each one a pure function that takes spacing, color, and opacity and draws that pattern to canvas. Adding a new pattern means writing one more renderer, not touching the ones that already exist.

State - the active pattern, spacing, unit, color, opacity - lives in a Zustand store, and every change flows straight through to the canvas via a debounced redraw, so dragging the spacing slider stays smooth instead of redrawing on every pixel of mouse movement.

Print uses the browser's native print pipeline against the same canvas you're already looking at, so there's no separate "export" step that might render differently from the on-screen preview.

Using It

Action	How
Pick a pattern	Click any pattern icon in the control panel
Set spacing	Drag the slider, or click the value and type a number
Switch units	Click mm or in next to the spacing value
Change color	Click the color swatch or the picker icon
Reset color	Click the ↺ reset button next to the picker
Adjust opacity	Drag the opacity slider
Flip ruler units	Click anywhere on the ruler at the top
Print	Click PRINT

Where This Fits In Your Workflow

• Bullet journaling - a dot grid at exactly the spacing your handwriting wants, not whatever spacing a specific notebook brand chose.
• Sketching and drafting - isometric or cross-hatch grids for 3D work and technical drawing, without buying a pad you'll use twice.
• Music composition - staff paper on demand, no trip to a music store for a single blank page.
• Teaching and worksheets - graph paper with bold major lines and light minor divisions, printed in the exact quantity a lesson actually needs.

Tech Stack

Technology	Purpose
React 19	UI framework
TypeScript	Type safety across pattern renderers and store
Tailwind CSS v4	Styling
Zustand	Grid and notification state
Vite	Build tool
use-debounce	Keeps slider-driven redraws smooth

Project Structure

gridpaper
├── public
│   └── favicon
├── src
│   ├── components
│   │   ├── Canvas          PatternRenderer
│   │   ├── Controls          ControlPanel, Ruler
│   │   └── UI                  Loader, Notification, PrintButton, SpacingControl, OpacityControl
│   ├── hooks                    useDebouncedGrid, useNotification
│   ├── patterns                  one renderer per grid type (dotGrid, drawHexGrid, drawMusicStaff, ...)
│   ├── store                      gridStore, notificationStore
│   ├── types
│   ├── utils
│   ├── App.tsx
│   ├── main.tsx
│   └── index.css
├── index.html
├── package.json
├── tsconfig.json
└── vite.config.ts

Getting Started

Prerequisites

• Node.js 18+ (LTS recommended)
• npm, yarn, or pnpm

Installation

Clone the repository and move into it.

git clone https://github.com/bilalmlkdev/gridpaper.git
cd gridpaper

Install dependencies and start the dev server.

npm install
npm run dev

For a production build:

npm run build

Contributing

Contributions are welcome - yes, even yours.

1. Fork the repository.
2. Create a feature branch: git checkout -b feature/amazing-feature
3. Commit your changes: git commit -m "Add amazing feature"
4. Push it: git push origin feature/amazing-feature
5. Open a Pull Request.

Keep to ES6+ syntax, format with Prettier, write commit messages that explain the reasoning, and check for console errors before submitting. If your change adds a pattern or a control, update this README's relevant section too.
